Type S13 Oil-Immersed Transformer

Distribution transformers are key equipment in power supply and distribution systems for industrial, mining enterprises and civil buildings. They step down the voltage of 10 (6) kV or 35 kV power grids to the 230/400 V bus voltage for end users. This series of products is applicable to alternating current of 50 (60) Hz. The maximum three-phase rated capacity is 2500 kVA, while the maximum single-phase rated capacity is 833 kVA (single-phase transformers are generally not recommended).
