S13 Type Oil-Immersed Transformer with Wound Three-Dimensional Core

The distribution transformer is one of the important equipment in the power supply and distribution systems of industrial and mining enterprises as well as civil buildings. It reduces the 10 (6) kV or 35 kV network voltage to the 230/400V bus voltage that is suitable for users. Such products are applicable to AC 50 (60) Hz, with a maximum three-phase rated capacity of 2500 kVA (single-phase rated capacity of 833 kVA, single-phase transformers are generally not recommended), and can be used indoo
